Scanning
Maximum Scan Size: 54 x 228 mm
Optical Scanning Resolution: 300 x 300 DPI
Colour Scanning: Yes (UV model excluded)
Duplex Scanning: Yes
Output Greyscale Depth: 8 Bit
Output Colour Depth: 24 Bit (UV model excluded)
Greyscale Levels: 256
Scan Speed (B/W): 45cpm
Scan Speed (Colour): 20cpm (UV model excluded)
Black/white Scanning Modes: Greyscale, Black & White, Error Diffusion, Fine Text Filtering
Scanner Type: Compact Cheque Scanner with ADF and imprinter
Sensor Type: CIS
Drivers: Canon Driver, Ranger
ADF Capacity: 50 Sheets
Scanning Media Types Supported: Cheque, Voucher & Coupon
ADF Media Weight: 64 - 157 g/m²
Scan Width: 54 - 108 mm
Scan Length: 95 - 228 mm
Long Document Mode: Up To 2000mm
Ports & interfaces
USB Port: Yes
Standard Interfaces: USB 2
Power
Power Supply Type: AC
Power Consumption: 15.8w
Power Consumption (Standby): 2.3w
Power Consumption (Off): 0.1w
Compatibility
Windows Operating Systems Supported: Windows 11
Windows 10 - 32 / 64 Bit
Windows 8 - 32 / 64 Bit
Windows 7 - 32 / 64 Bit
Windows Server Operating Systems Supported: Server 2008 R2 SP1
Server 2012 R2
Server 2016
Server 2019 (64-bit)
Server 2022 (64-bit)
Weight & Dimensions
Width: 140mm
Depth: 223mm
Height: 188mm
Weight: 2.1 Kg
Technical Details
MICR: E13B, CMC7
OCR: E13B, OCR-A, OCR-B, Cheque Writer, Universal Character
Sustainability Certificates: Energy Star, RoHS
Packaging Content
Windows Bundled Software: Canon Scanning Utility, Ranger Driver
Quick Start Guide: Yes
Cables Included: USB
Warranty Card: Yes
